V99 (40 Taper)

Vertical 3 & 4‑Axis

V99 (40 Taper)

Vertical 3 & 4-Axis

The V99 vertical machining center has been specifically designed to minimize thermal distortion for part precision and enhance higher quality finishes on die/mold output.


The V99 provides environmentally controlled machine accuracy enhancements, such as Makino’s patented core-cooled, under-race lubrication system that minimizes spindle distortion and twin shield-style splash guards to reduce the effect of temperature change in the factory.

Request a Quote

Technical Specifications

Available with either a 40-taper, 20,000/30,000-rpm or a 50-taper, 12,000/18,000-rpm spindle, the V99 can rough and finish hardened steel cavities/cores far more efficiently than general-purpose machines. Rigid linear guides and twin ballscrews are adopted for the Y-axis for a workpiece up to 4 tons.

The user-friendly, Makino Professional 6 control with Makino’s proprietary, next-generation Super Geometric Intelligence (SGI.5) software—developed specifically for high-feedrate, tight-tolerance machining of complex, 3-D contoured shapes involving continuous tiny blocks of NC data—ensures production rates faster than standard CNC systems while maintaining unsurpassed accuracy.


X: 1500 mm Y: 1000 mm Z: 800 mm

Spindle RPM

20000

Spindle Taper

BT40 (HSK-A63 opt)

Rapid Traverse

20,000 mm/min

Cutting Feedrate

20,000 mm/min

Maximum Workpiece

1800 x 1000 x 650 mm

Maximum Payload

4,000 kg

ATC Capacity

20 (30, 40, 80)

Tool to Tool

8 secs

Maximum Tool Diameter

120 mm

Maximum Tool Weight

8 kg
